We bought our 120Ah KS Energy Lithium
Battery in July 2021, 3 months after buying our first Motorhome. We used it only to power the hab lights and to the water pump, and occasionally to refill the inborad fresh water tank using a 19 ltr per minute Reicher submersible pump powered from the TV socket via a home made switch with long lead. The light usage caused a problem with the
Battery BMS in that it recharged itself via the
Solar almost instantly and then went into a deep sleep/standby mode. Almost exactly 1 hour after switching the 12v lights on in the evening, the fridge would call for a teaspoon of leccy to power the spark, but the
battery would be in too deep a sleep to respond, and the 12v system would cut out for 1 second before reconnecting. That 1 second trip was enough to lose the built in Sat Nav settings, throw a Fault Code on the Truma 6 Control Panel [warning of excessive power consumption, 'shut down all systema to preserve
battery power' message' and occasionally trip the 12v system switch on the Hab Control Panel, a total PITA every night!
On David Wildebus advice we managed to increase the load on the Lithium to stop it going into Sleep Mode, by fitting USB Chargers and a Trickle Charger that forces the Lithium to feed the Vehicle
Battery for 9 seconds in every 10 seconds, and that has solved the problem. David fitted an
Inverter for us in early Autumn 2022 and we gave it its first proper trial at Jeff & Lorraine's 3 Rallies over the last 2.5 weeks, using Induction Hobs, Kettles, Bike
Battery Chargers, Remoska, and anything else we could find to burn some power, to the extent that we overstretched the Lithium and cuased it, the
inverter and the van 12v Control Panel to go into alarm simultaneously, with lights and alarms triggering at the same time. This caused confusion for the BMS on the Lithium and was overcome by plugging into a mains socket overnight after 2 solid days of
solar recharging and NO
inverter usage had restored the SOC to only 6%! The Lithium has recovered from our over exuberant abuse of its resources and reached 100% SOC yesterday after about 100 miles of driving to top up 3 days
solar charge that totalled almost 2.5 Kwh!
Now that we have found out what the
Inverter/Lithium combination can offer with Slow Cookers/Remoskas etc, we will probably look to replace the 120Ah
battery with a 200 or 230Ah Lithium, so that we can play with anything/everything electric without throwing the power supply into overload. Had I treated a Lead Acid Leisure
Battery like I did the 120Ah Lithium over the last 2 weeks or so, I would have killed it. But the Lithium has recovered fully and returned for more, despite my idiotic usage. Lithium is a godsend for us!
Steve
